Qunkun Metal Products Co., Ltd. offers a wide range of fencing systems for residential, commercial, and industrial purposes.
Tube & Post products are widely used in metal fences for buildings and homes, offering versatility and durability.
Fence
Double Wire Mesh Fence is also called welded double horizontal wire fence or welded twin horizontal wire fence, which is made from mild or stainless steel. Which is composed of two horizontal wires and one vertical wire. With the strong, beautiful, wide-viewing and corrosion-resistant feature. It is mainly used in basketball courts, factories, parks and other places.
Share:
(1) High security, double barbed wire is stronger and prevents vandalism.
(2) Anti-corrosion, with galvanized coating on the surface, not easy to corrode and more durable.
(3) Easy to install and easy to operate.
(4) Beautiful appearance.
Specifications
Name | Specifications | ||
Panel Height | Mesh | Panel Length | |
Double Wire Fence Panel | 1.03m | 6/5/6 or 8/6/8 mm | 2.5m |
1.23m | 6/5/6 or 8/6/8 mm | ||
1.43m | 6/5/6 or 8/6/8 mm | ||
1.63m | 6/5/6 or 8/6/8 mm | ||
1.83m | 6/5/6 or 8/6/8 mm | ||
2.03m | 6/5/6 or 8/6/8 mm | ||
Name | Specifications | ||
Fence Post | Square post:40*60*1.2/1.5/2.0mm*2.0/2.2m or 60*60*1.2/1.5/2.0mm*2.4/2.0m | ||
Round post:48*1.5mm*2.0m;48*2.0mm*2.2m or 60*1.5mm*2.4 m;60*2.0mm*2.5m | |||
Peach post:70*100*1.0mm*2.5m or 70*100*1.2mm*2.5m |
Technology
Product Technical Information | |
Standard BS1722-14:2017 | |
BS EN ISO 1461:2009 | |
BS EN 13438:2013 | |
Panel Type | Mesh and wire.Single vertical and double horizontal wires.Note:Dulok Sports Rebound system panel type also available |
Panel Width | 2506mm |
Wire diameter | 6mmverticals and twin 8mm horizontals or 5mm verticals and twin 6mm horizontals. |
Mesh size | 200x50mm |
Available heights | 630mm to 6060mm.Fence heights above 3030mm are made up of 2 ormore panels |
Nominal Heights | 0.6 to 6.0m |
Finish | Polyester powder-coated to 60-80 microns or 160-200 microns with marine grade and metallcs.Any RAL colouravalilable |
Top Edge Projection | 30mm |
Panel Installation | Bottom of panel approx 40mm above ground |
Security Topping Options | Cranked or straight extensions for barbed and razor wire depending on height of panel |
Post Dimensions | 60mmx40mm to 120mmx60mm depending on height of panel |
Post Centres | 2520mm |
Posts | RHS,galvanised after manufacture and polyester powder-coated to match fencing |
Fixings | 40mmx 5mm full length clamp bar.M8x40mm stalnless steel pin hex dome-head security screws.Sheardrive"if required instead of pin hex. |
Foundations | Set posts in holes minimum 300mm diameter x 800mm deep.Note:Contractor/client is responsible for the foundation size suitable for the ground conditions and height of fence. |
Warranty | Minimum of 15 years against manufacturing defects. |
Application
Here are some common applications of Double Wire Mesh Fence:
Perimeter Security: One of the primary applications of Double Wire Mesh Fence is in providing perimeter security for commercial, industrial, and institutional properties. The sturdy construction and height of the fence make it difficult to breach, deterring unauthorized access and enhancing security.
Public Facilities: Double Wire Mesh Fence is often used around public facilities such as schools, parks, sports fields, and playgrounds to create a safe and secure boundary. It helps in controlling access and ensuring the safety of individuals using these spaces.
Highway and Railway Protection: This type of fence is commonly installed along highways, roads, and railway lines to prevent unauthorized entry onto the tracks or roads, enhancing safety for both pedestrians and vehicles.
Residential Perimeter Fencing: Double Wire Mesh Fence is also used in residential areas for securing homes and properties. It provides a robust barrier while maintaining visibility and aesthetics, adding value to the property.
Airport and Port Security: Airports, ports, and other high-security areas often utilize Double Wire Mesh Fence to establish secure perimeters and control access to restricted areas.
Industrial Sites: Industrial facilities, warehouses, and construction sites benefit from the security and durability offered by Double Wire Mesh Fence to protect assets, equipment, and materials from theft and vandalism.
Animal Enclosures: Double Wire Mesh Fence is suitable for creating animal enclosures in farms, zoos, and wildlife parks. The strong construction of the fence helps in containing animals safely within designated areas.
Parks and Recreational Areas: Public parks, recreational areas, and community spaces often use Double Wire Mesh Fence to demarcate boundaries, prevent unauthorized entry, and enhance safety for visitors.
Overall, the Double Wire Mesh Fence's versatility, strength, and aesthetic appeal make it a popular choice for a wide range of applications where security, safety, and boundary demarcation are essential.
Double Wire Mesh Fence
Double Wire Fence(656 / 868 )
Inquriy
If You Have Any Needs for Our Products
Please contact us no any hesitate. Our professional staff will contact you immediately and give you the most professional product acceptance and the best procurement plan. We sincerely welcome your inquiries
SEND INQUIRY NOW
Related Products
358 security product is a security product with high strength and excellent protective performance. This product widely covers prisons, military facilities, airports, borders and other places that require high security protection.
A Canada temporary fence is a type of fencing solution commonly used for short-term applications in various settings, such as construction sites, events, and outdoor activities.
Double Wire Mesh Fence is also called welded double horizontal wire fence or welded twin horizontal wire fence, which is made from mild or stainless steel.
Roll top fence also known as BRC fence,it is a protective facility that is bent at the top of the fence. And ensuring there are no sharp or raw edges. This type of fence is usually made of Q235 low-carbon steel wire, and is made through processes such as welding and bending. Bending can enhance the toughness and firmness of the fence, ensure its du
Curvy welded mesh fence, also known as 3D security fence, is a kind of specially designed welded wire mesh with V-shaped bending curves in its longitudinal direction.
Chain link fence is an elastic woven mesh with the characteristics of uniform mesh, flat mesh surface, beautiful appearance, simple weaving and strong practicality.
